Rene Rubalcava | March 16, 2021

Let there be highlight

When you're building a mapping application, there comes a time when you probably need to add some interactivity, a little excitement for your users. One of the quickest ways to do this with the ArcGIS API for JavaScript, is the highlight. The highlight provides a quick, yet effective way to let the user interact with features in the application. You could take advantage of the View events amd use a hitTest to quickly find features already drawn in the map. There's a good chance, users are not interacting with features they can't see. Because they are already available in the browser, accessing these features is wicked fast!

The pointer events, like pointer-move, don't return a mapPoint, but do return screen points. This is for performance reasons. Luckily, the hitTest expects screen coordinates, so you can pass it the event directly, and it will work its magic.

let highlight;

view.when(async () => {
    let layerView = await view.whenLayerView(layer);
    view.on('pointer-move', async (e) => {
        const {results} = await view.hitTest(e);
        const { graphic } =
            results.find(x => x.graphic.attributes.OBJECTID);
        if (highlight) {
            highlight.remove();
        }
        highlight = layerView.highlight(graphic);
    });
});

One thing to keep in mind, is that the hitTest will return information about the layer interacted with in vector tiles. This is typically used to for layer style updates, like paint properties of vector tiles. But in this case above, you only care about features from the FeatureLayer. So there needs to be some sort of filter in place for this.

Own that popup

If you really want to impress your mom users, you could add a Feature widget to display info that would normally be seen in the popup. I talked more about the Feature widget here.

view.when(async () => {
    let layerView = await view.whenLayerView(layer);
    view.on('pointer-move', async (e) => {
        const {results} = await view.hitTest(e);
        const { graphic } =
            results.find(x => x.graphic.attributes.OBJECTID);
        if (highlight) {
            highlight.remove();
        }
        // pass graphic to widget
        featureWidget.graphic = graphic;
        highlight = layerView.highlight(graphic);
    });
});

This is pretty simple. You create a Feature widget, place the DOM element where you want on your page, and then give it the graphic you get from the hitTest result. Nothing else for you to really do. It will automatically update based on the graphic and the PopupTemplate associated with the graphic.

Summary

There are numerous ways you could provide some form of interactivity to your mapping applications. I think using highlight is a great way to get started. If you find your users want something a bit more, like filters and effects, blending or more, you have a solid start to work from. And maybe, they'll be happy with this solution. Remember, simple and done is better than fancy and late.

You can see a live demo here, and watch a video on this topic below!
