Snowpack with the ArcGIS JSAPI

Snowpack with the ArcGIS JSAPI

Rene Rubalcava | February 1, 2021

Out in the Snow

The land of build tools is growing, and one that has become pretty popular is snowpack. What makes snowpack neat is that it really leverages ESM out of the box. Most other build tools work with ESM, but might rely on some transforms for commonjs or others. Plus, Snowpack is fast.

Let's assume I have a basic ArcGIS JSAPI app, that just displays a map. I'm going to use the ESM deployment with @arcgis/core, to really take advantage of that ESM goodness.

// src/index.js
import ArcGISMap from '@arcgis/core/Map';
import MapView from '@arcgis/core/views/MapView';
import Search from '@arcgis/core/widgets/Search';

const map = new ArcGISMap({
  basemap: 'topo-vector'
});

const view = new MapView({
  container: 'viewDiv',
  map: map,
  zoom: 10,
  center: [-118, 34]
});

const search = new Search({ view });

view.ui.add(search, 'top-right');

The only other step needed is to set up copying the static assets for the API.

I'll admit, coming from a background of setting up webpack and rollup to build apps, the set up for Snowpack is petty straightforward. It will see an index.html and any files it references to do its build. This is similar to how Parcel works, but I do like the little bit of config I can do with Snowpack.

Snowpack has a mount property that I can use to map my assets folder to the build folder. I also need it because I have a src folder, instead of an index.html in the root of my project.

// snowpack.config.js
module.exports = {
    mount: {
        "node_modules/@arcgis/core/assets": {url: "/assets", static: true, resolve: false},
        "src": "/",
    }
};

That's some minimal configuration for an application. Basically, we're telling Snowpack that our assets folder is static, so please do not try to bundle any code in there. Do not touch. I also set up the src folder as the root for my application.

At this point, I need to do one more thing. I need to set some browser config in my package.json.

## package.json
{
  "browser": {
    "fs": false,
    "path": false
  },
}

This will keep Snowpack from throwing errors when it hits some of the web assembly files in the API.

Do you want to build a Snowman

At this point, I can add a script to run a build, either in dev mode or prod.

## package.json
{
  "scripts": {
    "start": "snowpack dev"
  },
}

I can now run my build and everything works great! But it's not optimized. Snowpack is just going to load everything in ESM, when unbuilt, can be a couple of hundred files. Not really ideal. Even if I were to run this in prod mod, it still wouldn't be optimized. I can use @snowpack/plugin-webpack to accomplish this.

// snowpack.config.js
module.exports = {
    mount: {
        "node_modules/@arcgis/core/assets": {url: "/assets", static: true, resolve: false},
        "src": "/",
    },
    plugins: [["@snowpack/plugin-webpack"]]
};

But, there is one more thing I need to do. I need to add a script to copy the assets for a production build.

## package.json
{
  "scripts": {
    "start": "snowpack dev",
    "build": "snowpack build && npm run copy",
    "copy": "ncp ./node_modules/@arcgis/core/assets ./build//assets"
  },
}

But wait, didn't I add the mount for the assets in my snowpack.config.js? Yes, yes I did. But this doesn't seem to work in production. It looks like an issue with Snowpack at the moment, but looking at issues, it's known and being worked on. No big deal.

Now, with everything done, I can do a production build of my application!

Summary

For a while there, I was flipping tables trying to get Snowpack to work with the JSAPI. But recently, and in particular version 3, it seems to have gotten a bit easier. Configuration is minimal, which I really like, and it works great! I might be switching to Snowpack for my projects moving forward, I'm liking it that much. The fact that it will just load ESM for dev mode makes it really fast and that is very appealing.

You can find a dmeo repo here, and check out the video below for more details!
