Geometry Engine Line Intersects

I’ve been waiting for this one

One cool feature in the ArcGIS Maps SDK for JavaScript that I have been waiting for is an improved method for finding intersections! Up until recently, you could use the geometry engine to help you find if two lines intersected, or shared an edge. But they never returned a geometry for the intersection location. You could do it manually with some cuts of geometry, find the ends of the lines, which was kind of a pain. Now however, this functionality is built in!

Intersection bliss

There’s a function in the geometry engine called intersectLinesToPoints that does just what it promises. It will take two lines, and return an array of points where the intersect. How much simpler could it get?

Let’s say for example, that I am going to use the Sketch widget and want to find the intersections of what I draw against another layer. I could do something like this.

sketch.on("create", debounce(async ({ graphic, state, tool }) => {
	if (tool !== "polyline") return;
	// start
	if (state === "start") {
		ptLayer.removeAll();
		gLayer.removeAll();

		await whenOnce(() => !layerView.updating);

		const query = layer.createQuery();
		query.geometry = view.extent;
		const { features } = await layerView.queryFeatures(query);
		const geometries = features.map(({geometry}) => geometry);
		unionedGeom = await union(geometries);
	}
	// active
	if (state === "active") {
		const pointGeoms = await intersectLinesToPoints(
			graphic.geometry,
			unionedGeom
		);

		const ptGraphics = pointGeoms.map((x) => ({
			geometry: x,
			symbol: {
				type: "simple-marker",
				outline: {
					width: 1,
					color: [185, 45, 45, 1]
				},
				color: [240, 120, 50, 1]
			}
		}));

		ptLayer.removeAll();
		ptLayer.addMany(ptGraphics);
	}

}));

In this snippet, I’m waiting for the sketch to complete drawing. When it does, I find the features from a layer in my maps extent. I use those line features as an input to the geometry engine along with my drawn line to get the points where they intersect and display them on the map. This is a pretty straight forward use case for using the intersectLinesToPoints method of the geometry engine. You can utilize this tool in a ton of different ways, it just depends on what you need. You can find this demo here.

Summary

The intersectLinesToPoints method in the geometry engine is one that I have been wanting to see for a long time, and I’m sure I’m not the only one. It’s powerful tool that let’s you do even more spatial analysis in your web apps. I’m a fan of anything that let’s you do some cool stuff my geometries!

You can see a video of this tool in action below!
