ArcGIS Custom UI

You need weird stuff

I see a lot of user questions come across my desk about doing some kind of custom work when building apps with the ArcGIS Maps SDK for JavaScript. I’m not going to lie, some of you want to do some weird stuff. I get it, I get it, you have users with specific needs, some odd workflow, or your boss drew some sketch for an app on a napkin. Hey, we’ve all been there.

The ArcGIS Maps SDK provides a ton of out-of-the-box widgets to build awesome apps. Once in a while you need some custom component that needs to interact with the map or scene. Just our luck, we provide a sample for that!

Custom UI

Let’s assume you’re tasked with building a component that needs to display the center coordinates of the map at all times. I don’t know, but I’ve seen this type of interface in mapping apps before, so it’s feasible.

Let’s go ahead and make a React component, because of course you’re using React.

// src/CenterComponent.jsx
import { useState, useEffect } from 'react';
import { watch } from '@arcgis/core/core/reactiveUtils';
import './center-component.css';

const CenterComponent = ({ view, id }) => {
  const [center, setCenter] = useState(null);

  useEffect(() => {
    // Watch for changes on the View's Extent
    let handle = watch(
      () => view?.view?.extent,
      (value) => {
        const { latitude, longitude } = value.center;
        // Update the component's display
        setCenter(`${longitude.toFixed(4)}, ${latitude.toFixed(4)}`);
    });
    // Clean up any handles or event listeners
    // created in useEffect method
    return () => handle.remove();
  }, [view]);

 return <div id={id} className="center-component">Center: {center}</div>;
};

export default CenterComponent;

Off the hook

Ok, let’s break down how some of this works in React. We are going to use a couple of hooks from React.

• useState
• useEffect

The purpose of useState is pretty straightforward. It’s helpful to manage the internal state of the component, which would be the string value of the coordinates.

The purpose of useEffect, directly from the docs… Some components need to stay connected to the network, some browser API, or a third-party library, while they are displayed on the page. I would say that qualifies for our use case. Pay attention to the hooks dependency array. First the function that is returned is referred to as a cleanup function, the first function is called the setup. On a re-render, if something in the dependencies array has changed, the function the cleanup function runs, then the setup function runs.

The setup function uses reactiveUtils to watch for the MapView center to change. I talked more about reactiveUtils in this post here. When the center of the view changes, the local state is updated. In this component, the cleanup function removes the WatchHandle.

Using the Custom UI

We can now consume the custom component in our React application.

// src/App.jsx
function App() {
  const [viewState, setViewState] = useState(null);
  const centerComponentID = useRef("center-component");
  const mapDiv = useRef(null);

  useEffect(() => {
    // super awesome code here
  }, [mapDiv]);

  return <div className="mapDiv"ref={mapDiv}>
            <CenterComponent
                id={centerComponentID.current}
                view={viewState}>
            </CenterComponent>
         </div>;
}

export default App;

The main thing the CenterComponent needs is access to the view so it can watch for changes. The reason we do this is so that the internals of how this works can change in the future if it needs to. That’s all there is to it. Not too complicated, and now we can use this component across any of our React applications in our organization.

Summary

I kind of wish this was more complicated than it really is. Then I would have more to talk about. But in this case, when you know a little bit about building React components, you integrate functionality from the ArcGIS Maps SDK for JS pretty easily. This applies to doing the same thing with Vue, Svelte, Angular, Solid, whatever.

I’ve seen some pretty creative custom functionality built in various frameworks and stacks. So if you ever need to build some custom UI functionality for your application, this example should give you a pretty solid start. Good luck and build something awesome!
